Specications
1. Specications
Values in the rated torque, peak torque, rated rotation speed, and speed control range represent those in a state where the
gearhead is not combined.
Refer to the operating manual included with the motor for the motor model name.
z
30 W and 60 W
Model
Motor
BLM230HP
BLM460SHP
BLM260HP
Driver
BLE2D30-A BLE2D30-C BLE2D60-A BLE2D60-C
Rated output power
(Continuous)
30 W 60 W
Power
supply
input
Rated voltage Single-phase 100-120 VAC
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Single-phase 100-120 VAC
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Permissible
voltage range
–
15% to +10%
Rated frequency 50/60 Hz
Permissible
frequency range
±5%
Rated input
current
Single-phase: 1.1 A
Single-phase: 0.67 A
Three-phase: 0.39 A
Single-phase: 1.7 A
Single-phase: 1.0 A
Three-phase: 0.61 A
Maximum input
current
Single-phase: 3.3 A
Single-phase: 2.2 A
Three-phase: 1.2 A
Single-phase: 5.4 A
Single-phase: 3.5 A
Three-phase: 2.0 A
Rated torque 0.096 N·m 0.191 N·m
Peak torque 0.2 N·m (80 to 2000 r/min) 0.4 N·m (80 to 2000 r/min)
Rated rotation speed 3000 r/min
Speed control range 80 to 4000 r/min
*
*
There are products which maximum rotation speed is 3600 r/min depending on the type of gearhead.
Check the operating manual included with the motor.
z
120 W and 200 W
Model
Motor
BLM5120HP
BLM6200SHP
BLM5200HP
BLM7200HW
Driver
BLE2D120-A

BLE2D120-AM
BLE2D120-C

BLE2D120-CM
BLE2D200-C
BLE2D200-CM
Rated output power
(Continuous)
120 W 200 W
Power
supply
input
Rated voltage Single-phase 100-120 VAC
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Permissible
voltage range
-15% to +10%
Rated frequency 50/60 Hz
Permissible
frequency range
±5%
Rated input
current
*2
Single-phase: 2.7 A (2.8 A)
Single-phase: 1.7 A (1.7 A)
Three-phase: 1.02 A (1.02 A)
Single-phase: 2.4 A (2.5 A)
Three-phase: 1.4 A (1.5 A)
Maximum input
current
Single-phase: 7.4 A
Single-phase: 4.8 A
Three-phase: 3.3 A
Single-phase: 6.5 A
Three-phase: 4.3 A
Rated torque 0.382 N·m 0.637 N·m
Peak torque 0.8 N·m (80 to 2000 r/min) 1.15 N·m (80 to 2000 r/min)
Rated rotation speed 3000 r/min
Speed control range 80 to 4000 r/min
*1
*1
There are products which maximum rotation speed is 3600 r/min depending on the type of gearhead.
Check the operating manual included with the motor.
*2
Values in parentheses ( ) indicate those of drivers for electromagnetic brake motor.
