Oriental motor BLVD40NM User Manual

72 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

HM-5113-9

Brushless Motor and Driver Package

BLV

Series

Standard Type, Electromagnetic Brake Type

USER MANUAL (Basic Function)

Thank you for purchasing an Oriental Motor product.

This Manual describes product handling procedures and safety precautions.

•

Please read it thoroughly to ensure safe operation.

•

Always keep the manual where it is readily available.

Table of Contents

Other manuals for Oriental motor BLVD40NM

Operating Manual8 pages

Questions and Answers:

M
Michael ReedAug 9, 2025
Why is my Oriental motor BLVD40NM not rotating?
- H
  Howard ManningAug 9, 2025
  If your Oriental motor Engine isn't rotating, first ensure the driver and power supply are properly connected. If both the FWD and REV inputs are ON or OFF, turn either FWD or REV input ON. If the internal potentiometer is not adjusted, turn it clockwise to set the speed. Ensure the potentiometer is correctly selected: turn the M0 input OFF for the internal potentiometer, or ON for the external one. Check the external potentiometer or DC voltage connection. Finally, if the ALARM LED is blinking, it indicates a protective function has been triggered; refer to p.64 to reset the alarm.
T
tristanmacdonaldAug 15, 2025
What to do if my Oriental motor Engine rotates in the opposite direction?
- P
  piercerebeccaAug 15, 2025
  If your Oriental motor Engine rotates in the wrong direction, check the FWD and REV input connections. The motor should rotate clockwise when FWD is ON and counterclockwise when REV is ON. If you're using a gear ratio where the gearhead output shaft rotates opposite to the motor, or a combination type-hollow shaft flat gearhead, reverse the FWD and REV input operations. With the combination type-hollow shaft flat gearhead, ensure you are viewing the gearhead in the correct direction as the rotation direction changes based on the viewing direction.
M
Mark GonzalesAug 20, 2025
Why does my Oriental motor BLVD40NM not stop instantaneously?
- K
  Karen AllenAug 20, 2025
  If your Oriental motor Engine doesn't stop immediately, ensure the STOP-MODE input is OFF to enable instantaneous stopping. Also, consider whether the load inertia is too large; if so, reduce it.
D
danielmooreAug 27, 2025
How to fix unstable operation and excessive vibration in my Oriental motor Engine?
- G
  gbarnesAug 27, 2025
  If your Oriental motor Engine operation is unstable or the motor vibration is excessive, first check the alignment of the motor and gearhead output shaft with the load shaft. Misalignment can cause instability. Also, consider the effect of electrical noise. To check for noise, operate only the essential equipment (motor, driver, and required external equipment). If noise is present, keep away from noise sources, reconsider the wiring, use shielded cables, and install ferrite cores.
G
Gloria BryantSep 2, 2025
What to do if the electromagnetic brake of my Oriental motor BLVD40NM Engine does not hold the load?
- B
  Bonnie AllenSep 2, 2025
  If the electromagnetic brake on your Oriental motor Engine isn't holding the load, ensure the MB-FREE input is turned OFF. When MB-FREE is ON, the brake is disengaged.

Oriental motor BLVD40NM Specifications

General

Brand	Oriental motor
Model	BLVD40NM
Category	Engine
Language	English

Summary

Safety Precautions

Warning and Caution Statements

Critical safety warnings for injury or death, and cautions for property damage.

General Safety Guidelines

Precautions for Use

Electrical and Handling Precautions

Precautions for insulation tests, SSR use, static electricity, and component handling.

Preparation

Installation

Installation Location Requirements

Conditions and environmental requirements for product installation.

Load Installation Guidelines

Permissible Load Limits

Maximum radial and axial loads for output shafts.

Driver Installation

EMC Directive Compliance

Methods for installation and wiring to comply with EMC Directive.

Grounding and Static Precautions

Proper grounding methods and precautions against static electricity.

Connection

Power Supply Connection

Detailed steps for connecting the main power supply.

Motor and Driver Connection

Steps for connecting the motor power and signal connectors to the driver.

I/O Signal Connection

Connecting I/O signals to the driver's CN4 connector.

Input and Output Signal Functions

Communication Cable Connection

Instructions for connecting communication cables like MEXE02 or OPX-2A.

Connection Diagrams

Operation

Operation Overview and Methods

Motor Speed Setting

Methods for setting motor speed via internal/external means.

Motor Start and Stop Control

Acceleration and Deceleration Time Setting

Speed Response and Two-Speed Operation

Torque Limiting Function

Sink/Source Logic Selection

Multi-Motor Control

Extended Functionality with MEXE02

Starting MEXE02 Software

Setting Operation Data and Parameters

Using MEXE02 windows to edit operation data and parameters.

Test Operation Features

MEXE02 Setting Contents

Parameter Update Timing

Comprehensive Parameter List

Detailed list of MEXE02 parameters, settings, and update methods.

Function Setting Details

I/O Function Assignment

Alarm and Warning Configuration

Operation and Communication Settings

Protective Functions

Alarm Indicators and Reset

Understanding protective functions, alarm LED blinks, and reset procedures.

Detailed Alarm Lists

List of alarms, their causes, remedial actions, and reset methods.

Troubleshooting and Remedial Actions

Troubleshooting Common Issues

Guide to diagnosing and resolving common motor and driver operational problems.

Specifications

Technical Specifications

Detailed electrical and performance specifications for BLV Series.
