VCCX2 Controller Technical Guide
Status Screens
Refer to the following map when navigating through the Status
Screens. From the Status Screen, press <ENTER> to scroll
through the screens.
STATUS
OPER MODE
UNOCCUPY
SPC TEMP
XX.X
SPC RH
X.X %
SPACE TEMPERATURE
40ºF to 200ºF or 5ºC to 93ºC.
OPERATION MODE
This screen displays the current mode of operation. Options are:
• UNOCCUPY (Unoccupied)
• OCCUPIED
• OVERRIDE
• HOL UNOC (Holiday Unoccupied)
• HOL OCC (Holiday Occupied)
• FRC OCC (Force Occupied)
• FRC UNOC (Force Unoccupied)
• REM OCC (Remote Occupied)
• ZONE HEAT
• ZONE COOL
• ZONE OVR (Zone Override)
SPACE HUMIDITY
0.00% - 100%
SAT TEMP
XX.X
Supply Air Temperature
40ºF to 200ºF or 5ºC to 93ºC.
OAT TEMP
XX.X
OUTDOOR AIR TEMPERATURE
40ºF to 200ºF or 5ºC to 93ºC.
OAT RH
XX.X
OUTDOOR AIR HUMIDITY
RAT TEMP
XX.X
RETURN AIR TEMPERATURE
40ºF to 200ºF or 5ºC to 93ºC.
CO2LEVEL
XX.X
CO2 LEVEL
0.00 PPM to 9000 PPM
HVAC MODE
This screen displays the current HVAC Mode. Options are:
• OFF MODE
• VENT MODE
• COOL MODE
• HEAT MODE
• VENT RH
• COOL RH
• HEAT RH
• WARMUP
• PURGE
• DEFROST
• COOLDOWN
HVAC MODE
OFF MODE
APPENDIX B
-
VCCX2 LCD SCREENS
Status Screens
