VCCX2 Controller Technical Guide
Air Balance Screens
Refer to the following map when navigating through the Air
Balance Screens. From the Air Balance Screen, press <ENTER>.
AIR
BALANCE
MAX FAN
10.0 VDC
MAXIMUM FAN VOLTAGE
0.0 to 10.0 vdc
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is 10.0.
MIN FAN
0.0 VDC
MINIMUM FAN VOLTAGE
0.0 to 10.0 vdc
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is 0.0.
MAX EXH
10.0 VDC
MAXIMUM EXHAUST VOLTAGE
0.0 to 10.0 vdc
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is 10.0.
MIN EXH
10.0 VDC
MINIMUM EXHAUST VOLTAGE
0.0 to 10.0 vdc
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is 10.0.
APPENDIX B
-
VCCX2 LCD SCREENS
Air Balance Screens and Factory Test Mode Screen
