VCCX2 Controller Technical Guide
APPENDIX C
-
VCCX2 BACnet
®
VCCX2 BACnet
®
Parameters
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
RSMZ 4
Faults
AI: 214 Current RSMZ 4
Faults
See RSMZ Faults
Bits on page 132.
RSMZ 4
Lockouts
AI: 215 Current RSMZ 4
Lockouts
See RSMZ
Lockouts Bits on
page 132.
RSMZ 5
Condenser
Fan
AI: 216 Current RSMZ 5
Condenser Fan Signal
RSMZ 5
VFD
Comp
Perc
AI: 217 Current RSMZ 5
VFD Compressor
Percentage
RSMZ 5
Discharge
Pressure
AI: 218 Current RSMZ 5
discharge pressure
RSMZ 5
Suction
Pressure
AI: 219 Current RSMZ 5 Suction
pressure
RSMZ 5
Suction Line
Temp
AI: 220 Current RSMZ 5
Suction Line Temperature
RSMZ 5
Saturation
Temp
AI: 221 Current RSMZ 5
Saturation Temperature
RSMZ 5
Superheat
AI: 222 Current RSMZ5
Superheat temperature
RSMZ 5
EEV
Position
AI: 223 Current RSMZ 5
EEV valve position
RSMZ 5
Warnings
AI: 224 Current RSMZ 5
Warnings
See RSMZ
Warnings Bits on
page 132.
RSMZ 5
Comp VFD
Alarms 1
AI: 225 Current RSMZ 5
Comp VFD Alarms 1
See RSMZ
Alarms 1 Bits on
page 1324.
RSMZ 5
Comp VFD
Alarms 2
AI: 226 Current RSMZ 5
Comp VFD Alarms 2
See RSMZ
Alarms 2 Bits on
page 133.
RSMZ 5
Comp VFD
Drive
Status
AI: 227 Current RSMZ 5
Comp VFD drive status
See RSMZ
Drive Status Bits on
page 133.
RSMZ 5
Compressor
Current
AI: 228 Current reading in Amps
that the RSMZ 5
compressor is using
RSMZ 5
Discharge
Line Temp
AI: 229 Current RSMZ 5
discharge line temperature
RSMZ 5
Faults
AI: 230 Current RSMZ 5
Faults
See RSMZ Faults
Bits on page 132.
RSMZ 5
Lockouts
AI: 231 Current RSMZ 5
Lockouts
See RSMZ
Lockouts Bits on
page 132.
RSMZ 6
Condenser
Fan
AI: 232 Current RSMZ 6
condenser fan signal
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
RSMZ 6
Reheat
Valve 1
AI: 233 Current RSMZ 6
Reheat Valve 1
position
RSMZ 6
Discharge
Pressure
AI: 234 Current RSMZ 6
discharge pressure
RSMZ 6
Suction
Pressure
AI: 235 Current RSMZ 6
Suction Pressure
RSMZ 6
Suction Line
Temp
AI: 236 Current RSMZ 6
Suction Line Temperature
RSMZ 6
Saturation
Temp
AI: 237 Current RSMZ 6
Saturation Temperature
RSMZ 6
Superheat
AI: 238 Current RSMZ 6
Superheat Temperature
RSMZ 6
EEV
Position
AI: 239 Current RSMZ 6
EEV valve position
RSMZ 6
Suction
Pressure 2
AI: 240 Current RSMZ 6
Suction pressure 2
RSMZ 6
Suction Line
Temp 2
AI: 241 Current RSMZ 6
Suction Line Temperature 2
RSMZ 6
Saturation
Temp 2
AI: 242 Current RSMZ 6
Saturation Temperature 2
RSMZ 6
Superheat 2
AI: 243 Current RSMZ 6
Superheat Temperature 2
RSMZ 6
EEV
Position 2
AI: 244 Current RSMZ 6
EEV valve position 2
RSMZ 6
Warnings
AI: 245 Current RSMZ 6
Warnings
See RSMZ
Warnings Bits on
page 132.
RSMZ 6
Discharge
Line Temp
AI: 246 Current RSMZ 6
discharge line temperature
RSMZ 6
Faults
AI: 247 Current RSMZ 6
Faults
See RSMZ Faults
Bits on page 132.
RSMZ 6
Lockouts
AI: 248 Current RSMZ 6
Lockouts
See RSMZ
Lockouts Bits on
page 132.
SUB 1
Sub Cool 1
AI: 249 Current Subcooling
Module 1 Sub Cool 1
reading
SUB 1
Sub Cool 2
AI: 254 Current Subcooling
Module 1 Sub Cool 2
reading
SUB 1
Sub Cool 3
AI: 255 Current Subcooling
Module 1 Sub Cool 3
reading
SUB 1
Pressure 1
AI: 256 Current Subcooling
Module 1 liquid line
pressure 1 reading
