124
VCCX2 Controller Technical Guide
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
Outdoor Air
Dewpoint
Setpoint
AV: 26 On an MUA unit, if the OA
dewpoint rises above this
setpoint, Dehumidication is
initiated.
35°F
1.7°C
80°F
26.6°C
Economizer
Enable
Setpoint
AV: 27 The economizer is enabled
if the outdoor drybulb,
dewpoint, or wetbulb
temperature falls below this
setpoint.
-30°F
-34.4°C
80°F
26.6°C
Heat Wheel
Defrost
Enable
Setpoint
AV: 28 The unit will go into Heat
Wheel Defrost if the Outdoor
Air is below this setpoint.
0°F
-17.7°C
50°F
10°C
PreHeat
Enable
Setpoint
AV: 29 If the Supply Fan is energized
this is the temperature at
which the Preheat Relay will
activate or the Preheat-X will
activate. Operates only in the
Occupied Mode.
-30°F
-34.4°C
70°F
21.1°C
Sensor Slide
Oset Max
Eect
AV: 30 If your space sensor has the
optional slide adjustment
feature, this is the maximum
amount the slide can adjust
the current heating and
cooling setpoints up or down
with full deection of the
slide.
0°F
0°C
10°F
5.5°C
Space Sensor
Calibration
Oset
AV: 31 If the Space Temperature
Sensor is reading
incorrectly, you can use this
option to enter an oset
temperature to adjust the
Sensor’s Temperature.
-100°F
-55.5°C
100°F
55.5°C
Supply Air
Sensor
Calibration
Oset
AV: 32 If the Supply Air
Temperature Sensor is
reading incorrectly, you can
use this option to enter an
oset temperature to adjust
the Sensor’s Temperature.
-100°F
-55.5°C
100°F
55.5°C
Return Air
Sensor
Calibration
Oset
AV: 33 If the Return
Temperature Sensor is
reading incorrectly, you can
use this option to enter an
oset temperature to adjust
the Sensor’s Temperature.
-100°F
-55.5°C
100°F
55.5°C
Outdoor Air
Sensor
Calibration
Oset
AV: 34 If the Outdoor
Temperature Sensor is
reading incorrectly, you can
use this option to enter an
oset temperature to adjust
the Sensor’s
Temperature.
-100°F
-55.5°C
100°F
55.5°C
Carbon
Dioxide
Sensor
Calibration
Oset
AV: 35 If the CO
2
Sensor is
reading incorrectly, you can
use this option to enter an
oset value to adjust the
Sensor’s CO
2
reading.
-500 500
Low Ambient
Protection
Setpoint
AV: 36 Temperature at which the
Low Ambient Relay will
activate in the Occupied or
Unoccupied Mode.
-30°F
-34.4°C
70°F
21.1°C
APPENDIX C
-
VCCX2 BACnet
®
VCCX2 BACnet
®
Parameters
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
SAT Cool
Setpoint
Reset Source
Low Limit
AV: 37 If doing Supply Air Setpoint
Reset, this is the Low Reset
Source value in Cooling
that will correspond to the
Supply Air Cool High Reset
Setpoint.
-30°F
-34.4°C
150°F
65.5°C
SAT Cool
Setpoint
Reset Source
High Limit
AV: 38 If doing Supply Air Setpoint
Reset, this is the High Reset
Source value in Cooling that
will correspond to the Supply
Air Cooling Setpoint (Low
Reset).
0°F
-17.7°C
150°F
65.5°C
SAT Heat
Setpoint
Reset Source
Low Limit
AV: 39 If doing Supply Air Setpoint
Reset, this is the Low Reset
Source value in Heating that
will correspond to the
Supply Air Heating High
Reset Setpoint.
-30°F
-34.4°C
150°F
65.5°C
SAT Heat
Setpoint
Reset Source
High Limit
AV: 40 If doing Supply Air Setpoint
Reset, this is the High Reset
Source value in Heating that
will correspond to the Supply
Air Heating Setpoint
(Low Reset).
0°F
-17.7°C
150°F
65.5°C
Control
Temperature
High Alarm
Oset
AV: 41 If the temperature of the
controlling sensor rises
above the Occupied Cooling
Setpoint by this value, a
High Control Temp Alarm
will occur. Only applies
if congured for Space or
Return Air Temp Control, or
as Single Zone VAV.
0°F
0°C
50°F
27.7°C
Control
Temperature
Low Alarm
Oset
AV: 42 If the temperature of the
controlling sensor falls
below the Occupied
Heating Setpoint by this
value, a Low Control Temp
Alarm will occur. Only
applies if congured for
Space or Return Air Temp
Control, or as Single Zone
VAV.
0°F
0°C
50°F
27.7°C
Heat Pump
Compressor
Heat Lockout
AV: 43 Compressor Heat will
be locked out below this
setpoint.
-30°F
-34.4°C
100°F
37.7°C
Maximum
Main Fan
VFD in
S Z VAV
Heating
Mode
AV: 44 In Single Zone VAV
conguration, this is the
max fan speed the VFD can
modulate up to in Heat Mode.
0 100
Minimum
Main Fan
VFD in
Cooling
Mode
AV: 45 In Single Zone VAV
conguration, this is the
fan speed at which the VFD
will start when Cooling
is initiated. In a VAV
conguration this is the
lowest fan speed allowed in
the Cooling Mode. In CAV
and MUA congurations this
should be set to 100%.
0 100
