VCCX2 Controller Technical Guide
RSMZAlarms2StatusBits ::= ENUMERATED {
Service Trip Read/Write (0)
Service Trip (Reserved) (1),
Service Trip Type Code/Spare Part (2),
Service Trip (Reserved) (3),
Service Trip (Reserved) (4),
Reserved (5),
Reserved (6),
Reserved (7),
Reserved (8),
Discharge High (9),
Start Failed (10),
Speed Limit (11),
External Interlock (12),
Illegal Option Combi. (13),
No Safety Option (14),
Reserved (15),
Reserved (16),
KTY Error (17),
Fans Error (18),
ECB Error (19),
Reserved (20),
Reserved (21),
Reserved (22),
Reserved (23),
Reserved (24),
Current Limit (25),
Reserved (26),
Reserved (27),
Reserved (28),
Encoder Loss (29),
PTC Thermistor (30),
Dangerous Failure (31)
}
RSMZDriveStatusBits ::= ENUMERATED {
Control_Ready (0=Control Not Ready;
1=Control Ready) (0)
Drive_Ready (0=Drive Not Ready;
1=Drive Ready) (1),
Enable (0=Coasting; 1=Enable) (2),
Trip_Error (0=No Error; 1=Trip) (3),
ErrorNoTrip (0=No Error; 1=Error (no trip)) (4),
Reserved (5),
Triplock_Error (0=No Error;
1=TripLock (must power cycle)) (6),
Warning (0=No Warning; 1=Warning) (7),
SpeedEqualsReference (0=Speed; !=Reference;
1=Speed=Reference) (8),
BusControl (0=Local Operation; 1=Bus Control) (9),
FreqLimitOkay (0=Out of Frequency Limit;
1=Frequency Limit Okay) (10),
InOperation (0=No Operation; 1=In Operation) (11),
Stopped_AutoStart (0=Drive OK;
1=Stopped,, Auto Start) (12),
VoltageExceeded (0=Voltage Okay;
1=Voltage Exceeded) (13),
TorqueExceeded (0=Torque Okay;
1=Torque Exceeded) (14),
TimerExceeded (0=Timer Okay;
1=Timer Exceeded) (15)
}
