SPECIFICATIONS
1. Continuous 4W load 20Hz to 20kHz, < 0.05% THD, with input voltage at 13.8VDC.
2. Continuous 2W load 20Hz to 20kHz, < 0.1% THD, with input voltage at 13.8VD.
Amplifier Section
Power Output 4W Stereo (Watts)
1
200 x 2
Power Output 2W Stereo (Watts)
2
400 x 2
Power Output 4W Mono (Watts) 800 x 1
Remote Gain Capable Yes
Distortion at Rated Power < 0.1% THD+N
Frequency Response 20Hz to 20kHz ±0.25dB
Linear Bandwidth 10Hz to 50kHz ±3dB
Signal-to-Noise Ratio at Rated Power > 100dB
Damping Factor > 200
Input Sensitivity 200mV to 5V
Input Impedance 10kW
Fuse Type 100 Amp MAXI
Dimensions 23.4" x 10.5" x 2.4"
Weight 10 lbs.
Crossover Section
Low Pass Crossover Continuously Variable
2nd Order / 4th Order
Low Pass Frequency Range 20Hz to 3kHz
High Pass Crossover Continuously Variable
2nd Order
High Pass Frequency Range 10Hz to 3kHz
INTELLi Q 10dB boost
4
©2004 Directed Electronics, Inc.
