Orion LCD Monitor User Manual

Trigger
Option Function Value
Trigger Enable Activates the trigger feature. Off or On
Trigger Input Selects the input source for the Trigger.
AV1, AV2, RGB-PC, DVI
or HDMI
Buzzer Inactivated.
Trigger Time
Selects the amount of time, in seconds,
that the monitor displays the trigger Input image.
3 ~ 100
Trigger Option Selects the type of physical trigger input. See table below.
Display Type
Selects the mode in which the monitor displays
the Trigger Input. The monitor takes one of the
following actions:
- PIP & FULL: Displays the Trigger Input in the PIP
of the current video input source.
Note: The main video source must support the
Trigger Input source as a PIP option. See section
“Input Source” in “C. PIP”.
- FULL: Switches the display to show the Trigger
Input in the full screen.
PIP & FULL or FULL
- 15 -
