A. Rear Connection
1. AV2 OUT
2. AV2 IN
3. AV1 OUT
4. AV1 IN
5. TRIGGER IN
6 & 7. AUDIO R & L (AV1 & AV2)
8. PC STEREO IN (VGA & DVI)
9. VGA
10. DVI
11. HDMI
12. DC12V
- 7 -
1 10 2 3 4 5 6
7
8
9
11
12
