Orion OLM-5510 User Manual

- 74 - - 75 -
ORION
Innitely Expandable
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255) 
*CheckSum:execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
3.17. Tracking Mode
- A command for adjusting alignment manually or automatically or loading the predetermined values at PC RGB
mode only.
- CMD: 0x4A (Auto-tracking), 0x4B (Get Tracking Values), 0x4C (Frequency- tracking), 0x4D (Phase-tracking),
0x4E (Line-Start tracking), 0x4F (Pixel-Start tracking)
- It is available only on Power On (Operative) status.
- Send to MLCD
A. NormalCommand
STX CMD Length
Data
ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 0x03
B. Broad-CastCommand
STX CMD Length Data: ID ETX
Value 0x02 Variable 0x01 0x00 0x03
C. Frequency/Phase/Line-Start/Pixel-Start-tracking(NormalCommand):AdjustingPC(RGB)screenmanually.
STX CMD Length
Data
ETX
ID Master Tracking Value
Value 0x02 Variable 0x03 Variable 0X01 Variable 0x03
D. Frequency/Phase/Line-Start/Pixel-Start-tracking(Broad-CastCommand):AdjustingPC(RGB)screenmanually.
STX CMD Value Length
Data
ETX
ID Tracking Value
Value 0x02 Variable 0x02 0x00 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*Broad-cast:AllLCDsetswillexecutethesamecommand,whentheIDis0x00.Noresponse(Onewaycommand)
*"GetTrackingValue"commandcannotbeusedfor"Broad-cast"command.
-Frequencyvaluerange:77(0x4D)~177(0xB1) /RealValue(-50~+50)  /RealValue+127(0x7F)
-Phasevaluerange:127(0x7F)~190(0xBE) /RealValue(0~+63)  /RealValue+127(0x7F)
-LineStartvaluerange:104(0x68)~137(0x89) /RealValue(-23~+10)  /RealValue+127(0x7F)
-PixelStartvaluerange:77(0x4D)~167(0xA7) /RealValue(-50~+40)  /RealValue+127(0x7F)
- Receive from MLCD
A. Auto-tracking,Frequency/Phase/Line-Start/Pixel-Start-tracking
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 Variable 0x03
B. GetTrackingValues
STX CMD Length
Data
Check Sum ETX
ID Master Tracking Value
Value 0x02 Variable 0x06 Variable 0X01 … Variable 0x03
Frequency Phase LineStart PixelStart
Variable Variable Variable Variable
*IDrange(Program):0x01(1)~0xFF(255)
*TrackingValue
-Frequencyvaluerange:77(0x4D)~177(0xB1) /RealValue(-50~+50)  /RealValue+127(0x7F)
-Phasevaluerange:127(0x7F)~190(0xBE) /RealValue(0~+63)  /RealValue+127(0x7F)
-LineStartvaluerange:104(0x68)~137(0x89) /RealValue(-23~+10)  /RealValue+127(0x7F)
-PixelStartvaluerange:77(0x4D)~167(0xA7) /RealValue(-50~+40)  /RealValue+127(0x7F)
*CheckSum:execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
3.18. White Balance Control
- Command for adjusting Gain R/G/B and Offset R/G/B for White balance
- The adjusted value is not applied during Stand-by or No-signal status. MLCD must be operating status and
there must be the input signal of each mode.
- To apply the same configuration to all MLCD sets, the "ID" area value can be set as "0x00." However, considering
differences between sets, individual adjustment for white balance is recommended.
- CMD: 0xAC (Gain R), 0xAD (Gain G), 0xAE (Gain B), 0xB0 (Offset R), 0xB1 (Offset G), 0xB2 (Offset B)
- Send to MLCD
A. NormalCommand
STX CMD Length
Data
ETX
ID Master Control
Value 0x02 Variable 0x03 Variable 0x01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*Control:“0(0x00)”~“255(0xFF)”
- Receive from MLCD
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 Variable 0x02 Variable 0x01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:Execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
3.19. Firmware Default Set (Picture Control Data)
- Initialize the LCD set. All the settings will be returned to the initial condition prior to the adjustment in the factory.
Pre-programmed value will be applied.
- It is available only on Power On (Operative) status.
- Since previous Picture Control Data will be lost with this command. High caution is required.
- Send to MLCD
STX CMD Length
Data
ETX
ID Master
Value 0x02 0x81 0x02 Variable 0x01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*Itisnotapplicableas"Broad-cast"command.
- Receive from MLCD
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 0x81 0x02 Variable 0x01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
MLCD
