Orlaco 0506972 - Additional Zoom Camera Serial Commands

10 IM0973171 A 01
Installation Manual
14. Additional zoom camera serial commands
V_ZOOM 0x07
V_ZOOM_STOP 0x00
V_ZOOM_TELE 0x27
V_ZOOM_WIDE 0x37
V_ZERO_LUX 0x01
V_ZEROLUX_ON 0x02
V_ZEROLUX_OFF 0x03
V_BACKLIGHT_COMP 0x33
V_BACKLIGHT_COMP_ON 0x02
V_BACKLIGHT_COMP_OFF 0x03
V_FOCUS 0x08
V_FOCUS_FAR 0x23
V_FOCUS_NEAR 0x33
V_FOCUS_STOP 0x00
V_AUTOFOCUS 0x38
V_AUTOFOCUS_ON 0x02
V_AUTOFOCUS_OFF 0x03
V_PRESET 0x3f
V_PRESET_SET 0x01
V_PRESET_RECALL 0x02
Zoom in:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZOOM> <V_ZOOM_TELE> <V_TERMINATOR>
Zoom out:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZOOM> <V_ZOOM_WIDE> <V_TERMINATOR>
Zoom stop:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZOOM> <V_ZOOM_STOP> <V_TERMINATOR>
Zerolux on:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZERO_LUX> <V_ZEROLUX_ON> <V_TERMINATOR>
Zerolux off:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_ZERO_LUX> <V_ZEROLUX_OFF> <V_TERMINATOR>
Backlight compensation on:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_BACKLIGHT_COMP> <V_BACKLIGHT_COMP_ON> <V_TERMINATOR>
Backlight compensation off:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_BACKLIGHT_COMP> <V_BACKLIGHT_COMP_OFF> <V_TERMINATOR>
Autofocus off:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_AUTOFOCUS> <V_AUTOFOCUS_OFF> <V_TERMINATOR>
Autofocus on:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_AUTOFOCUS> <V_AUTOFOCUS_ON> <V_TERMINATOR>
Focus near:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_FOCUS> <>V_FOCUS_NEAR <V_TERMINATOR>
Focus far:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_FOCUS> <>V_FOCUS_FAR <V_TERMINATOR>
Focus stop:
<0x80 + address> <V_COMMAND> <V_CATEGORY_CAMERA1> <V_FOCUS> <>V_FOCUS_STOP <V_TERMINATOR>
