6. PROGRAMMABLE PARAMETERS TABLE
Here below is a description of all the parameters available on
the instrument. Some of them may not be present, either due
to the fact they depend on the type of instrument or because
they are automatically disabled as unnecessary.
Parameter Description Range Def. Note
1
SLS
Minimum Set Point -99.9 ÷ SHS -50.0
2
SHS
Maximum Set Point SLS ÷ 999 99.9
3
SP
Set Point SLS ÷ SHS 0.0
4
SPE
Set Point Eco SP ÷ SHS 0.0
5
iuP
Unit of measurement and
resolution (decimal point)
C0 - °C, resolution 1°;
F0 - °F, resolution 1°;
C1 - °C, resolution 0.1°;
F1 - °F, resolution 0.1°.
C1
6
iFt
Measurement filter oF ÷ 20.0 s 2.0
7
iC1
Pr1 Probe Calibration -30.0 ÷ +30.0°C/°F 0.0
8
iC2
Pr2 Probe Calibration -30.0 ÷ +30.0°C/°F 0.0
9
iCU
Display offset -30.0 ÷ +30.0°C/°F 0.0
10
iP2
Input Pr2 usage
oF - Unused;
EP - Evaporator probe;
Au - Auxliary probe;
dG - Digital Input.
dG
11
iFi
Function and logic
functioning of the Digital
Input (adding the “-” minus
sign the logic is inverted)
0 - No function;
-2/ -1/1/ 2 - Open Door;
-3/3 - Open Door with Output Lock;
-4/4 - External Alarm;
-5/5 -
External alarm with output
disabling;
-6/6 - Normal/Eco select;
-7/7 - On/Stand by select;
-8/8 - Do not use.
0
12
iti
Digital Input Delay
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
oF
13
iEt
Eco Mode activation delay
at Door closed
oF - Disabled;
-1 ÷ -59 (min)
/ 1 ÷ 99 (hrs).
oF
14
itt
Max. time functioning in
Eco Mode
oF - Disabled;
-1 ÷ -59 (min)
/ 1 ÷ 99 (hrs).
oF
15
idS
Variable normally dis-
played
P1 - Probe Pr1 measure;
P2 - Probe Pr2 measure;
P3 - Do not use;
Ec - Measure Pr1 in Normal mode
+ ECO label when in ECO mode;
SP - Set Point;
oF - Display not lit.
P1
16
rd
Differential (Hysteresis) 0.0 ÷ 30.0°C/°F 2.0
17
rEd
Differential (Hysteresis) in
ECO mode
0.0 ÷ 30.0°C/°F 2.0
18
rt1
Output activation time for
Pr1 probe error
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
oF
19
rt2
Output deactivation time
for Pr1 probe error
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
oF
20
rHC
Output operating mode
H - Heating;
C - Cooling;
nr - Do not use;
HC - Do not use;
C3 - Do not use.
C
21
dtE
Defrosting finishing
temperature
-99,9 ÷ 999 ºC / ºF 10.0
22
dtS
Temperature from which
the beginning of the
defrosting is allowed.
-99,9 ÷ 999 ºC / ºF 2.0
23
dtF
Temperature that forces
the beginning of the de-
frosting.
-99,9 ÷ 999 ºC / ºF -99.9
24
dSt
Delay in the beginning of
a defrosting because of
evaporator probe
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
1
25
ddL
Display Lock during defrost
oF Not active;
on Active at last measure;
Lb Active with label (dEF during
defrost and PdF at defrost).
Lb
Parameter Description Range Def. Note
26
dcd
Defrost activation time for
continuous compressor
operating
oF - Disabled;
-1 ÷ -59 (min)
/ 1 ÷ 99 (hrs).
oF
27
dde
Defrost duration
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
30
28
dPE
Probe mode of the end of
the defrost:
oF - Disabled;
EP - EP probe temperature;
P1 - Probe temperature Pr1;
oF/EP/P1
EP
29
ddi
Defrosting interval
oF - Disabled;
-1 ÷ -59 (min)
/ 1 ÷ 99 (hrs).
6
30
dSd
Delay first defrost after
power-on
oF - Disabled;
-1 ÷ -59 (min)
/ 1 ÷ 99 (hrs).
6
31
PP1
Out delay at switching-on
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
oF
32
PP2
Out delay after switching
OFF
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
oF
33
PP3
Delay between two output
switching-ON
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
oF
34
Pod
Output delay at power ON
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
oF
35
AAy
Temperature Alarm 1 type
1 -
Absolute for Pr1 with Hi-Lo label;
2 - Relative to Pr1 with Hi-Lo label;
3 - Absolute for Au with Hi-Lo label ;
4 -
Relative to Au with Hi-Lo label ;
5 - Absolute for Pr1;
6 - Relative to Pr1;
7 -
Absolute for Au ;
8 - Relative to Au.
1
36
AHA
High temperature Alarm
threshold
oF - Disabled;
-99.9 ÷ +999°C/°F.
oF
37
ALA
Low temperature Alarm
threshold
oF - Disabled;
-99.9 ÷ +999°C/°F
oF
38
AAd
Temperature Alarms
Differential
0.0 ÷ 30.0°C/°F 1.0
39
AAt
Temperature Alarms Delay
oF - Disabled;
-1 ÷ -59 (sec) ÷ 1 ÷ 99 (min).
oF
40
APA
Temperature Alarms delay
at power ON
oF - Disabled;
-1 ÷ -59 (min)
/ 1 ÷ 99 (hrs).
2
41
AdA
Temperature Alarms delay
and
unlock display delay
after defrost
oF - Disabled;
-1 ÷ -59 (min) / 1 ÷ 99 (hrs).
-5
42
AoA
Open Door Alarm Delay
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 99 (min).
3
43
tUF
Key Function
oF - No function;
1 - Do not use;
2 - ECO Mode selection;
3 - Switch ON/Switch OFF (Stand-by);
4 - Do not use.
3
44
tFb
/ Key Function oF
45
tLo
Keyboard lock function
delay
oF - Disabled;
-1 ÷ -59 (sec) / 1 ÷ 30 (min).
oF
46
tEd
Set Point visibility with
set
key fast procedure
0 - None;
1 - SP;
2 - SPE;
3 - SP and SPE;
4 - Active SP;
5, 6 - Do not use.
4
47
tPP
Password to Access
Parameter functions
oF - Disabled;
001 ÷ 999.
oF
