OSAKA - F 100 / TSF 100 / M1 - Manual de Usuario – V2.1 - PAG. 6
5 – LIST OF PARAMETERS
Parameter listing. Some of them might be on the menu with
password and some without, shortcut or may not be present
depending on the model:
Par.
Description
Range
Def.
Note
S. – Parameters Set Point value to regulate
1
S.LS
Minimum Set Point
-99.9 ÷ HS
-50.0
2
S.HS
Maximum Set Point
LS ÷ 999
99.0
3
SP
Set Point
-LS ÷ HS
0.0
i. - Probe parameters selection and correction
4
i.SE
Type of probe
Pt / nt
nt
5
i.uP
Unit of measure and
resolution (decimal
point)
C0 = ° C without p.dec
1º
F0 = ° F without p.dec
1º
C1 = ° C with 0.1 ° dec
F1 = ° F with 0.1 ° dec
C0 / F0 / C1 /
F1
C1
6
i.Ft
Measuring filter
oF ÷ 20.0
sec
2.0
7
i.C1
probe calibration
-30.0 ÷ 30.0
°C/°F
0.0
r. – Parameters of temperature regulation
8
r.d
Differential
(Hysteresis) regulation
0.0 ÷ 30.0
°C/°F
2.0
9
r.t1
Output relay activation
time for probe faulty or
broken
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
oF
10
r.t2
Stop time relay output
for faulty sensor or
broken
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
oF
11
r.HC
Operating mode
output:
H = Heat (heat)
C = Cold (cold)
H - C
C
d. – Defrost Control Parameters
12
d.di
Interval between
defrost
oF/ 0.01 ÷ 9.59
(h.min. ) ÷ 99.5
(hrs.min.x10)
6.00
13
d.Sd
Delay to start
defrosting
(oF = defrost at start)
oF/ 0.01 ÷ 9.59
(h.min. ) ÷ 99.5
(hrs.min.x10)
6.00
14
d.dE
Duration defrost
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
30.0
15
d.dL
Block display during
defrost:
oF = not active
on = Active with last
measure
Lb = active with
abbreviations ("dEF"
defrosting and "PdF" in
Post-defrost
recovering)
oF - on - Lb
Lb
P. Parameters relating to the protection of the compressor
and delay starting.
16
P.P1
Exit delay activation
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
oF
17
P.P2
Disabling postarrest
output (relay)
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
oF
18
P.P3
Minimum time after two
starts departure.
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
oF
19
P.od
Output activation delay
at start (supply)
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
oF
A. – Alarm parameters
20
A.Ay
Temperature alarm
type:
1 = Absolute
2 = Relative
1 / 2
(/ 3 / 4 / 5 / 6 /
7 / 8 = No use)
1
21
A.HA
Set alarm for high
temperature
oF / -99.9 ÷
999 °C/°F
oF
22
A.LA
Set alarm for low
temperature
oF / -99.9 ÷
999 °C/°F
oF
23
A.Ad
Differential
temperature alarm
0.0 ÷ 30.0
°C/°F
1.0
24
A.At
Temperature alarm
delay
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
oF
25
A.PA
Delay of temperature
alarm at start (power)
oF/ 0.01 ÷ 9.59
(h.min. ) ÷ 99.5
(hrs.min.x10)
2.00
26
A.dA
Delay of temperature
alarm after defrost
defrost lock display
oF/ 0.01 ÷ 9.59
(h.min. ) ÷ 99.5
(h.min.x10)
0.05
o. – Buzzer alarm configuration parameters
27
o.bu
buzzer operation
oF = disable
1 = one alarm
2 = only for keyboard
use
3 = active alarm and
keypad
oF / 1 / 2 / 3
3
t. – Keyboard Configuration Parameters
28
t.UF
Operation mode key
"F" or .
oF = no function
4 = On / stop (Stand-
by)
oF / 4
(1 / 2 / 3 = No
use)
4
29
t.Lo
Automatic keyguard
oF/ 0.01 ÷ 9.59
(min.sec ) ÷
30.0
(min.sec.x10)
oF
30
t.PP
Password access to
operating parameters
oF ÷ 999
oF
6 – TROUBLESHOOTING, MAINTENANCE AND WARRANTY
6.1 – SIGNALS
Error
Reason
Action
E1 -E1
The relative probe can
be broken (E) or in short
circuit (-E), or may have
a value that is out of
range programmed
Check the connection of
the probe to the
instrument and verify the
correct operation of the
probe. (it helps to have
the ohms values of the
probes)
EPr
Possible anomaly in
EEPROM
Press the SET key.
Power cycle the
instrument
Err
Fatal Error device
memory
Replace the device or
send it to any repair
