Osaka F 300 - TROUBLESHOOTING AND WARRANTY; FAILURE WARNINGS; ERRORS; WARRANTY AND REPAIR; TECHNICAL DATA

OSAKA - F 200 / F 300 / TSF 200 / TSF 300 / M3 - User Manual - V.2 - PAG. 12
“t” – Keyboard Configuration Parameters
Par.
Description
Range
Def.
Note
59
t.UF
Operation mode key
"F" (U)
oF = No Function
1 = Command auxiliary
output
2 = Command
Continuous Cycle
3 = Active Set Point
Selection
4 = Start / Stop (Stand-
by)
oF / 1 / 2 / 3 / 4
4
60
t.Fb
Down key operating
mode / Aux: see "t.UF"
oF / 1 / 2 / 3 / 4
oF
61
t.Lo
Automatic keypad lock.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 30.0
(min.sec)
oF
62
t.PP
Password access to
the operating
parameters.
oF ÷ 999
oF
63
t.AS
Device address for
serial communication
MODBUS
0 ÷ 255
1
6 – TROUBLESHOOTING, MAINTENANCE AND WARRANTY
6.1 – FAILURE WARNINGS / ERRORS
Error
Reason
Action
E1-E1
E2-E2
E3-E3
The probe can be
interrupted (E) or short (-
E), or measuring a value
outside the allowable
range.
Check the connection of
the probe to the instrument
and verify the correct
operation of the probe. (it
helps to have the values of
the probes ohms)
Epr
Possible anomaly in
EEPROM
Press Set button
Err
Memory error
irreversible, disrepair
device
Replace the product or
sent for repair
Otras indicaciones:
Display
Indicator
Reason
od
Delay-start after power equipment
Ln
keypad Locked
Hi
High temperature alarm in progress
Lo
Low temperature alarm
AL
Digital input alarm in progress
oP
open door
dEF
Active defrost, indication if "d.dL" = Lb
PdF
Defrost finish recovering cold if "d.dL" = Lb
CC
Continuous cycle in progress.
6.2 - CLEANING
Se recomienda de limpiar el Termostato solo con un paño húmedo
sin detergente o con detergente neutro.
6.3 – WARRANTY AND REPAIR
This device has a guarantee in form of repair or replacement by
manufacturing defects in materials of 12 months from the date of
purchase.
OSAKA SOLUTIONS automatically void this guarantee and is not
liable for any damages deriving from:
- Use, installation, or use and handling undue, others than
those described above and, in particular, differs from the
safety requirements established by the regulations.
- Use in applications, machines or electrical panels that do not
provide adequate protection against liquids, dust, grease and
electric shocks to the installation conditions made.
- The inexperienced handling, and / or alteration of the product.
- The installation / use in applications, machines or electrical
panels do not comply with the valid norm.
In case of defective product under warranty or out of that period, it
should contact the post sales service to perform the necessary
steps. Request document repair "RMA" (by mail or fax) and
complete it, is necessary send the RMA and the device to SAT
OSAKA by method prepaid.
7 – TECHNICAL DATA
7.1 – ELECTRICAL FEATURES
Supply: 100...240 VAC +/- 10%
Frequency AC: 50/60 Hz
Consumption: 3 VA APROX.
Inputs /i: 3 inputs for NTC temperature probe (103AT-2, 10 K Ω @
25 °C) or PTC (KTY 81-121, 990 Ω @ 25° C)
Relays Outputs: Up to 3 Relays
F 200 / TSF 200: OUT 1: 16A-AC1 (9A-AC3) / 250 VAC
OUT 2: 8A-AC1 (3A-AC3) / 250 VAC
F 300 / TSF 300: OUT 1: 16A-AC1 (9A-AC3) / 250 VAC
OUT 2: 8A-AC1 (3A-AC3) / 250 VAC
OUT 3: 5A-AC1 (2A-AC3) / 250 VAC
M3: OUT 1: 14A-AC1 (6A-AC3) / 250 VAC
OUT 2: 8A-AC1 (3A-AC3) / 250 VAC
OUT 3: 4A-AC1 (2A-AC3) / 250 VAC
Relay Output Electrical life: 100000 operations
Power supply: EN 60730-1 type 1.B
Overvoltage Category: II
Device Class: Class II
Insulation: (power 115/230 V and relay output); and part low
voltage inputs; Electrically isolated between output and power
7.2 – MECHANICAL FEATURES
Body: Plastic self-extinguishing UL 94 V0
Category of resistance to heat and fire: D
Weight: 115 g approx.
Connection: Terminal block 2,5 mm2
Pollution Degree: 2
Ambient operating temperature: 0 ... 50 ° C
Operating humidity: 95HR% no condensing
Storage and transport temperature: -25 ... 60 ° C
7.3 – FUNCTIONAL FEATURES
Temperature regulation: ON / OFF
Defrost control: interval for compressor failure.
Measuring range: NTC: -50 ... 109 ° C / -58 ... 228 ° F; PTC: -50 ...
150 ° C / -58 ... 302 ° F
Display resolution: 1 ° or 0.1 ° (between -99.9 ... 99.9 °)
Total accuracy: + / - (0.5% FS + 1 digit)
Time measured speed (no filter): 130 ms
Display: 3 Digits Reds (optional Blue) h 15.5 mm
Software class structure: Class A
Compliance: Directive 2004/108/EC (EN55022 class B, EN61000-
4-2: 8KV air, 4KV cont; EN61000-4-3. 10V / m, EN61000-4-4: 2KV
power, inputs, outputs; EN61000-4-5: com 2KV power mode, 1 kV \
diff mode, EN61000-4-6:.. 3V), 2006/95/EC (EN 60730-1, EN
60730-2-7, EN 60730-2 -9)
