Series 2 Oil-Fired Steam Boilers – Boiler Manual
Part Number 550-110-772/0816 23
Table 8 Parts list for Figure 15
11 Replacement parts continued
Figure
number
Description Boiler model
number
Part number
A Wide front section, number 7121 All 316-700-326WT
B Intermediate section, number 7015 All 316-700-065WT
C Back section, number 7027 (steam, no top tapping) OSB-3, -4, & -5 316-700-329WT
D Back section, number 7027 (steam, top tapping) OSB-6 316-700-312WT
E
Section replacement kit, front or back section
(for 1 joint, includes seals, rope, adhesive and collector hood hardware)
All 386-700-852WT
Section replacement kit, intermediate section
(for 2 joints, includes seals, rope and adhesive)
All 386-700-851WT
Section assembly complete
OSB-3 326-700-408WT
OSB-4 326-700-409WT
OSB-5 326-700-410WT
OSB-6 326-700-411WT
F Standard Collector hood kit for back outlet
(includes rope and hardware for installation)
OSB-3 386-700-237WT
OSB-4 386-700-238WT
OSB-5 386-700-239WT
OSB-6 386-700-240WT
G
Tie rod ½ x 12-
1/4" OSB-3 560-234-493WT
Tie rod ½ x 15-
3/8" OSB-4 560-234-532WT
Tie rod ½ x 18-
1/2" OSB-5 560-234-475WT
Tie rod ½ x 21-
5/8" OSB-6 560-234-536WT
H Heater cover plate carton (Cover plate, gasket, studs and nuts) All 389-900-103WT
I Tankless heater carton, 35-S-29 (Heater, gasket, studs and nuts) All 386-700-350WT
J
Combustion chamber kit
(rear and front refractory, door refractory blanket and water glass)
All 386-700-836WT
Burner mounting door assembly
(door, observation port, rope, insulation and pins)
All 343-500-546WT
K Burner mounting door, number 7171 All 381-355-797WT
L Door hinge, number 7054 All 330-054-300WT
M Door refractory All 592-400-028WT
N Door refractory blanket All 591-222-115WT
P Observation port shutter All 460-039-867WT
Q Door seal rope 5 feet All 590-735-105WT
R Glass rope 3/8" for collector hood (7 feet for largest size hood) All 590-735-109WT
Flue brush, 123D All 591-706-214WT
