Osburn MATRIX User Manual

Matrix Insert Installation and Operation Manual
8 _______________________________________________________________________________
2 GENERAL INFORMATION
2.1 MATRIX INSERT SPECIFICATIONS
Fuel Type Cordwood
Test Standards (safety) ULC S628, UL 737 and UL 1482
Test Standard (emissions) EPA Method 28 (40 CFR Part 60)
Heating capacity range* 750 to 2100 sq. ft. (47 to 195 m
2
)
Maximum heat output**
(EPA test fuel)
32 200 BTU/h (9,4 kW/h)
Maximum heat output**
(natural hardwood fuel)
75 000 BTU/h (22 kW/h)
Optimum efficiency 77,2 %
Test Standard (efficiency) CSA B415.1-10
Approximate Burn Time 6 to 8 hours
Shipping Weight 474 lb ( 215 kg)
Firebox Volume 2,4 cu.ft. (0,068 m
3
)
Maximum Log Length 20" east-west***
Flue Outlet Diameter 6" (150 mm) diameter (vertical)
Baffle Material C-Cast
* Burn time and heating capacity may vary subject to location in home, chimney draft, chimney
diameter, locality, heat loss factors, climate, fuels and other variables.
** The EPA test fuel is dimensional Douglas fir pieces stapled together into cribs with air spaces
between. We also test using the same procedure except using split hardwood firewood to reflect
real-world heat output. This insert is not intended to operate at its peak heat output continuously.
*** East-west: through the door you see the sides of the logs; north-south: through the door you
see the ends of the logs.

Osburn MATRIX Specifications

General

Maximum Output	75, 000 BTU/h
Emissions	1.54 g/h
Firebox Volume	2.4 cu. ft.
Blower	Optional
Burn Time	Up to 8 hours
Material	Steel
EPA Certified	Yes
Type	Wood-burning fireplace
Maximum Log Length	20 inches
Firebox Lining	Brick
