oset 16.0 - OSET 16.0 Specifications; Performance; Chassis Details; Motor and Controller

10
SPECIFICATIONS - OSET16.0
Performance:
- Maximum Speed - 15mph
- Maximum Range - 8 miles
- Weight Limit (Rider) - 80lbs (36.5kg)
NOTE!
Many factors affect speed and range capabilities. Terrain, average speed, rider
weight, tire pressures, wind, hills etc all have an impact.
Chassis:
- Frame - Steel
- Suspension (Front) - Telescopic air fork. Adjustable rebound
- Suspension (Rear) - Spring & oil type, adjustable rebound.
- Wheels - Aluminum alloy, 36H hubs.
- Tires - 2.5” x 16” wide front
- 2.7” x 16” wide rear
- Brakes - Hydraulic disc, 160mm.
- Foot pegs - Alloy.
- Handlebars - Alloy.
Motor:
- 800w 36v - Rare earth neodymium magnet motor
Controller:
- 36 volt, 80 amp pulse width modulating, with inline relay and fuse.
- External speed dial, power dial and throttle ‘map/response’ dial.
Throttle:
- Twist type with LED battery charge indicator.
Batteries:
- 3 X 12 volt 10 amp hour sealed lead acid AGM. 3 batteries in series.
- Dimensions - 151mm x 65mm x 110mm (each).
Keys, Dials and Ports:
- Key Switch and handlebar switch.
-Throttle map/response dial. Tunable response.
-Speed dial. Speed adjustment
-Power dial. Overall power adjustment.
- 36 Volt Charger Port.
Size:
- Wheelbase - 36” (914mm)
- Seat Height - 19 ” (482mm)
- Ground Clearance - 8.5” (216mm)
- Handlebar Height - 33.5” (851mm)
- Weight (without batteries) - 43.5 lbs (19.8kg)
- Weight (with batteries) - 63.5 lbs (28.8kg)
