oset 16.0 - OSET 20.0 Specifications; Performance; Chassis Details; Motor and Controller

12
SPECIFICATIONS – OSET
20.0
Performance:
- Maximum Speed - 15/20mph
- Maximum Range - 10 miles
- Weight Limit (Rider) - 100lbs
(45.5kg)
NOTE!
Many factors affect speed and range capabilities. Terrain, average speed, rider
weight, tire pressures, wind, hills etc all have an impact.
Chasis:
- Frame - Steel
- Suspension (Front) - Telescopic air fork. Adjustable rebound
- Suspension (Rear) - Spring & oil type, adjustable rebound.
- Wheels - 19” aluminum alloy, 36H hubs.
- Tires - 2.5” x 20” wide front & rear.
- Brakes - Hydraulic disc, 160mm.
- Foot pegs - Alloy.
- Handlebars - Alloy.
Motor:
- 1200 watt brush type. 48 volt.
- Gearing – 10T front sprocket, 86T rear. #219 chain.
Controller:
- 36 volt, 80 amp pulse width modulating, with inline relay and fuse.
- External speed dial, power dial and throttle ‘map/response’ dial
Throttle:
- Twist type with LED battery charge indicator.
Batteries:
- 4 X 12 volt 10 amp hour sealed lead acid AGM. 4 batteries in series.
- Dimensions - 151mm x 65mm x 110mm (each).
Keys, Dials and Ports:
- Key Switch and handlebar switch.
-Throttle map/response dial. Tunable response.
-Speed dial. Speed adjustment
-Power dial. Overall power adjustment.
- 48
Volt Charger Port.
Size:
- Wheelbase - 41.5” (1040mm)
- Seat Height - 21.5 ” (545mm)
- Ground Clearance - 10.5” (265mm)
- Handlebar Height - 37” (985mm)
- Weight (without batteries) - 49 lbs (22.2kg)
- Weight (with batteries) - 79 lbs (35.8kg)
