7. Description of motor with cable
The motor may not be dismantled!
The motor bearings are lubricated for life. No oil lubrication or other maintenance is necessary.
To prevent the instrument on the motor attachment from turning during the transmission, the locking pin supplied
can be pushed into one of the two holes (see illustration). The locking pins can only be used in combination with
straight and contra-angle handpieces that have corresponding holes.
Test run
– Start the motor.
– If you observe dysfunctions (e.g. vibrations, unusual noise, overheating, coolant supply failure or leakage) contact your
authorized service organization (see Page 41 – 43).
