Factory settings (P1 – P5)
P1 P2 P3
Transmission ratio 1:1 20:1 20:1
Factory setting rpm 35 000 1 200 800
Adjustable range rpm 300 – 40 000 15 – 2 000 15 – 2 000
Motor direction forward forward forward
Pump on on on
Factory setting Ncm max. max. max.
Adjustable range Ncm – – –
Intermediate stage Ncm – – –
P4 forward P4 reverse P5
Transmission ratio 20:1 20:1 1:1
Factory setting rpm 15 30 35 000
Adjustable range rpm – – 300 – 40 000
Motor direction forward reverse forward
Pump on off on
Factory setting Ncm 20 50 max.
Adjustable range Ncm 5 – 50 5 – 50 –
Intermediate stage Ncm 32 32 –
