MOTOR BASE PARTS
Everything you process begins with the motor base. The multi-speed motor
base will maintain a desired speed, automatically compensating for the changing
load of the various accessories. The drive shaft is permitted to move slightly
from side to side to provide a “free floating” feature to reduce noise and wear.
The motor is powerful, but it can be overloaded. To avoid this possibility,
closely follow the instructions and use the quantities specified in the recipes
in this book.
The motor base consists of three parts:
(A) CONTAINER HOLDER-For attaching the
blender,
arm, salad maker,
and optional accessories to the motor base.
TURNTABLE BASE-For positioning the mix-
ing bowls.
(C)
SPEED CONTROL PANEL-For controlling the
motor base. It consists of the following parts:
1. CONTROL DIAL-Located in the upper
hand corner of the panel. Turn the knob to
the right to increase speed and to the left to
decrease speed.
OFF BUTTON-For turning the unit “OFF.”
3. ON BUTTON
-
For continuous motor operation.
4. PULSE BUTTON-activates the motor when
held in-used for controlled cycle blending.
Use this only for blender operation. Also can
be used to stop the motor momentarily by
pressing and releasing the button.
NOTE: Speed Selection
For Blender Operation-
refer to the Blending Guide which is located on the Control
Panel. Match the numbers to the words and dial the correct speed. Remember, the
words are not descriptive of the blending action but only a reference for the speed
used in the Oster recipes.
For Mixer Operation-
refer to the Mixing Guide which is located on the Handle of the
Mixer/Doughmaker Arm. Match the numbers to the words and dial the correct speed.
The words in the Mixing Guide describe the mixing task you wish to perform.
