OTC OTC3208 - Page 11

|
OTC3208
|
Operating instructions | 11
en
575512 REV A | 05.2015Bosch Automotive Service Solutions Inc.
PID PID description
AECD8_
TIME1, TIME 2
Total Run Time with EI-AECD
#8 Timer 1 Active, #2 Timer
Active
AECD9_
TIME1, TIME 2
Total Run Time with EI-AECD
#9 Timer 1 Active, #2 Timer
Active
ALCOHOL Alcohol Fuel Percent
BARO PRS Barometric Pressure
BAT_PWR
Hybrid Battery Pack Remain
-
ing Life
BP_A_ACT, B_
ACT
Boost Pressure Sensor A, Sen
-
sor B
BP_A_CMD,
B_CMD
Commanded Boost Pressure
A, Pressure B
BP_A_STAT, B_
STAT
Boost Pressure A Control Sta
-
tus, B Control Status
CACT 11, 12
Charge Air Cooler Temper
-
ature Bank 1 Sensor 1 sup-
ported, Sensor 2 supported
CACT 21,22
Charge Air Cooler Temper
-
ature Bank 2 Sensor 1 sup-
ported, Sensor 2 supported
CALC LOAD Calculated Engine Load
CAT TEMP11,
TEMP12
Cataltic Converter Temp
Bank1, Temp Bank 3
CAT TEMP21,
TEMP22
Cataltic Converter Temp
Bank2, Temp Bank 4
CLR DIST Distance since erase
CLR TIME Minutes Run since Erase
CLR TRPS Warmups Since Erase
CMD EQ RAT
Commanded Equivalence
Ratio
COOLANT Engine Coolant Temp
DPF_REG_
AVGD
Average Distance Between
DPF Regen
DPF_REG_
AVGT
Average Time Between DPF
Regen
DPF_REG_
STAT
Diesel Particulate Filter (DPF)
Regen Status
DPF_REG_TYP
Diesel Particulate Filter (DPF)
Regen Type
DPF_REGEN_
PCT
Normalized Trigger for DPF
Regen
PID PID description
DPF1_DP,
DPF2_DP
Diesel Particulate Filter (DPF)
Bank 1 Delta Pressure Bank 2
Delta Pressure
DPF1_INP,
DPF2_INP
Diesel Particulate Filter (DPF)
Bank 1 Inlet Pressure, Bank 2
Inlet Pressure
DPF1_INT,
DPF2_INT
DPF Bank 1 Inlet Temperature
Sensor, Bank 2 Inlet Tempera
-
ture Sensor
DPF1_OUTP,
DPF2_OUTP
Diesel Particulate Filter (DPF)
Bank 1 Outlet Pressure,
Bank 2 Outlet Pressure
DPF1_OUTT,
DPF2_OUTT
DPF Bank 1 Outlet Temper
-
ature Sensor, Bank 2 Outlet
Temperature Sensor
ECT 1, 2
Engine Coolant Temperature
1, Temperature 2
EGR CMD Comanded EGR
EGR ERR
Exhaust Gas Recirculation
Error
EGR_A_ACT,
B_ACT
Actual EGR A Duty Cycle / Posi
-
tion, B Duty Cycle / Position
EGR_A_CMD,
B_CMD
Commanded EGR A Duty
Cycle / Position, B Duty Cycle /
Position
EGR_A_ERR,
B_ERR
EGR A Error, B Error
EGRT 11, 21
Exhaust Gas Recirculation
Temperature Bank 1 Sensor 1,
Bank 2 Sensor 1
EGRT 12, 22
Exhaust Gas Recirculation
Temperature Bank 1 Sensor 2,
Bank 2 Sensor 2
EGT 11, 21
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 1, Bank
2 Sensor 1
EGT 12, 22
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 2, Bank
2 Sensor 2
EGT 13, 23
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 3, Bank
2 Sensor 3
EGT 14, 24
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 4, Bank
2 Sensor 4
EMIS_SUP
Emission requirements to
which vehicle is designed
ENG RUN Time Since Engine Start
