Ourmeter LD-S700 - Instrument Specifications and Parameters; Power and Current Specifications; Environmental Specifications; Error Code Definition

7. Instrument
specifications and
parameters
1) 24V,36V,48V power
supply
2) Rated working current of
meter is 10mA
3) The maximum working
current of the meter is 30mA
4) Shutdown leakage
current <1uA
5) Supply controller working
current 50mA
6) Operating temperature:
-18~65 ℃
7) Storage temperature: -
30~80 ℃
8. Error code
definition
S700 can provide warning to vehicle faults. When a fault is
detected, the LCD displays the Error icon, and the ERROR code
N is displayed at the location of the ERROR code, and the
