Outback Excel 100T User Manual

2
1. Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
CODE PART QTY
OUTBACK®
EXCEL 100T
OUTBACK®
EXCEL 200T
OUTBACK®
EXCEL 300T
HOOD
A1 Hood (Pre-Assembled to Body) 1
√ √ √
A2 Hood Handle 1
√ √ √
A3 Warming Rack 1
√ √ √
BODY
B1 Barbecue Body 1
√ √ √
B2 Burner 1
√ √ √
B3 Control Panel 1
√ √ √
B4 Knob 2
√ √ √
B5 Hose (if supplied)

B6 Lava Rock in Basket 1
√ √ √
B7 Cooking Grill 1
√ √ √
B8 Ignition Button 1
√ √ √
B9 Control Panel Heat Shield 1
√ √ √
B10 Main Electrode 1
√ √ √
B11 Hinge Bracket 2
√ √ √
B12 Body Heat Shield 1
√ √ √
B13 Body Support 2
√ √ √
B14 Grease Cup Holder 1
√ √ √
B15 Grease Cup 1
√ √ √
TROLLEY
C1 Trolley Handle 1
√
C2 Side Shelf (with bracket)

1
C3 Side Shelf (without bracket)

1 1
C4 Side Shelf Bracket A

1 1
C5 Side Shelf Bracket B

1 1
C6 Side Burner Knob

1
C7 Side Burner Grid

1
C8 Side Burner Shelf

1
C9 Side Burner

1
C10 Side Burner Electrode

1
C11 Side Burner Valve / Hose Assembly

1
C12 Left Front Leg 1
√ √ √
C13 Left Rear Leg 1
√ √ √
C14 Right Front Leg 1
√ √ √
C15 Right Rear Leg 1
√ √ √
C16 Hose Tidy 1
√ √ √
C17 Gas Bottle Holder 1
√ √ √
C18 Leg End Loop 1
√ √ √
C19 Wheel Spacer 2
√ √ √
C20 Wheel 2
√ √ √
C21 Axle 1
√ √ √
C22 Bottom Shelf 1
√ √ √
C23 Gas Bottle Strap 1
√ √ √
HARDWARE
D1 M6x15 Bolt

24 28 28
D2 M5x10 Bolt 4
√ √ √
D3 M4x10 Bolt

1
D4 ST4.0x10 Screw 7
√ √ √
D5 ST4.0x15 Screw

4 4
D6 ST4.8x15 Screw 2
√ √ √
D7 M8 Locknut 2
√ √ √
D8 M5 Nut 2
√ √ √
D9 Spacer

2 10 6
 Pre-Assembled Component
 Quantity varies according to model purchased
Appearance, size, and construction may differ according to model
