Attach the Upper Support (C12) to the left/right cabinet panel using M6x15 Bolts (D3x4pcs).
3
4
C18
Attach the Storage Unit (C18) onto the Bottom Panel (C17) using M6x15 Bolts (D3x4pcs) as
shown.
D3
Bottom View
D3
D3
C12
