8
5
6
Carefully turn the cabinet upside-down.
Unscrew the Locknuts (C23) from both ends of the Axle (C22).
Slide the axle through the corresponding holes in the
left cabinet panel. Slide the Wheels (C20)
over each end of the axle. Secure the wheels into place with the locknuts. Place the Wheel
Hubcaps (C21) onto the outside of the wheels.
Attach the Lockable Casters (C19x2pcs) into the rear side holes of the right cabinet panel, as
shown.
C20
C19
C22
C23
C21
C19
