Outback Trekker User Manual

5
2
C3
C4
Assembly
IMPORTANT!
 Remove any internal components or packaging from the barbecue body.
 Whilst every care is taken in the manufacture of this product, care must be taken during assembly in
case sharp edges are present.
 Please read the Important Information section carefully before assembly and use of your
barbecue.
1
Attach the Tool Hooks (C5) and Legs (C1) onto the Leg Supports (B10) using Wing Bolts (D1x3pcs)
by placing a Wing Bolt through the loop of a tool hook and then into each leg as shown.
Note: The tool hooks are to be installed on the front of two legs only.
C1
C5
D1
Attach the Shelf (C4) onto the legs by aligning the snap hooks underneath the shelf with the Shelf
Supports (C3), and pressing down to secure it in place.
