Model No. 084-6693-4

• Repeat the same at the rest of the T-joint with Spring Mechanism, as

shown below.

• After completing the assembly, the Trampoline Frame and Mat should look

like the illustration below.

Note:

• The even distribution of tension is a critical factor in the proper

assembly of the Trampoline Mat.

• If the Springs (11) can only be inserted with the use of extensive

force, they are not inserted in the correct order and manner.

• Make sure that the Springs (11) are always inserted at an angle

of approximately 90° to the holes on the Top Rail Frame.

ASSEMBLY
