Model No. 084-6693-4

ASSEMBLY

STEP 13: Attaching the frame pad

• Place both Frame Pads (12) on the trampoline and secure them together

with the pre-sewn hook-and-loop tapes at the end of each pad.

• Connect the pre-sewn hook-and-loop tapes at the inner side of the frame

pad and the net.

STEP 12: Assembling the enclosure net

• Slide the Fiberglass Rod (19) into the passage at the top of the Net. Connect

the Fiberglass Rod (19) together by the Fiberglass Rod Connector (20) and

place the joined fiber glass rod into the slot of the ball cap.
