Step 1: Preparation
• Place the Top Rail Tubes (9A & 9B), T-Joint (4), T-Joint with Spring
Mechanism (5), Vertical Leg Tubes (6) and W-shaped Tubes (7) on a level
surface, as shown in the picture below. This provides an overview of the parts
and the way they should be assembled.
• The two types of T-Joints (4 & 5) must be alternately placed (4 – 5 – 4 – 5)
before connecting the top rail pieces.
Step 2: Assembling the vertical leg tubes
• Connect the Vertical Leg Tube (6) with W-shaped tubes (7).
Ensure spring-loaded locking pins are aligned with locking holes and pin
locks into the secured position.
9B
9B
9B
9B
9B
9B
9B
9B
9B
9B
9A
7
6
9A
4
5
6
6
7
ASSEMBLY
