4.4. FINAL PHASE
Proceed with flying the remaining elements till you
complete the array, making sure that all the locking
pins are positioned correctly.
The last steps to follow are:
1. tie the cables together to create a well-ordered
bundle as the array goes up;
2. once reached the necessary height, fix the array
with the ropes to regulate the vertical and hori-
zontal inclination according to the project;
3. fix the safety lock if used.
The same steps, with the only difference in the au-
dio connector on the rear panel of the loudspeaker,
are to be followed both for Superfly and for Mantas 28.
The total compatibility between their hardware par-
ts (figure 35) allows different configurations as long
as they are approved by OpenArray2 project.
figure 35
figure 36
