5. secure the front hardware parts and then the
rear ones, remembering that the whole pro-
cedure will be the same but to be done on the
contrary (figure 44). This means that it will be
possible to choose the inclination once the ele-
ment has been stacked and the front hardwa-
re has been locked (the higher the grade, the
higher will be the inclination of the upper ele-
ment) (figure 45);
6. repeat the procedure for all the elements ac-
cording to the OpenArray2 project, while also
doing the cabling (figure 46);
figure 44
figure 46
figure 45
7. perform the disassembly exactly on the con-
trary respect to the assembly procedure.
4. mount the element upon the frame upside
down (180°) to have the rear hardware looking
upwards;
