Oval EL0122 - 12 Product Code Explanation; El0122

E-122-8-E

12. PRODUCT CODE EXPLANATION
12.1 Model EL0122
●
Main code
① ② ③ ④ ⑤ ⑥
Model
E L 0 1 2 2 Totalizer/External power type
⑦
—
⑧
Power supply
J 85 to 264ACV
T 85 to 264ACV w/Battery for LCD when power off
⑨
Input signal
B Voltage pulse 12VDC 2 wires/3 wires
C Current pulse 12VDC (PG30S)
D Current pulse 24VDC (4/20mA)
G Open collector pulse 12VDC 2 wires/3 wires
K Contact pulse 12VDC 2 wires/3 wires
Z Special
⑩
—
⑪ ⑫
Output item 1
Pulse output
B 1 Pulse width 1ms
B 5 Pulse width 50ms
B 9 Pulse width other than above
S Y Input synchronous output
Z Z Special
⑬
Always N
N Always N
⑭ ⑮
Output item 2
Pulse output
N N Non
A L Alarm output (upper or lower alarm). Chose one when alarm output is chosen.
⑯
Always N
N Always N
⑰ ⑱
Output item 3
Analog output
N N Non
A 2 1 to 5V
A 5 4 to 20mA
A 7 4 to 20mA+1 to 5V
Z Z Other than above
⑲
Always N
N Always N
⑳
Version code
A Version A
󰼼
—
󰽇
Characteristic
0 Standard
Z Special
⑧−⑥⑤④③②① ㉒⑮⑭⑬⑫⑪−⑨ ⑳⑲⑱⑰⑯ −
Model
Power supply
Input signal
Characteristic
Always N
Always N
Output item 2
Output item 3
Always N
Version code
Output item 1
Main code
/ / / Additional code
Special test
A 1 0 Taxed custody transfer
A 3 0 Taxed alcohol
A 5 0 Specic measuring instruments
Document
D S J DWG and specications for approval (Japanese)
D S E DWG and specications for approval (English)
D R 0 Re-submission of DWG and specications
D C J Final DWG (Japanese)
D C E Final DWG (English)
D W J Wiring diagram (Japanese)
D W E Wiring diagram (English)
D T J Inspection procedure (Japanese)
D T E Inspection procedure (English)
C B J Inspection certicate: B set
Witnessed by customer
V 1 0 Required
●
