E-122-8-E
Name Terminals Description
Power
6
L1
7
L2
85-264V AC, 50/60Hz
(Model EL0122 only)
(+) (−)
or 12−24V DC±10% (Model EL0123 only)
Ground (8) To be earth grounded
Pulse
Input
Contact-closure
or open collector
PG20 Flowpet - 5G,
(N)PG60A(E3)
1, 2, 3 EL0122 1: 12V DC 2: SIG.
(+) 3: 0V
(−)
2, 3 EL0123 2: SIG. (+) 3: 0V
(−)
Voltage pulse
PG30
(N)PG60A(F)
1, 2, 3 EL0122 1: 12V DC 2: SIG.
3: 0V
2, 3 EL0123 2: SIG. 3: 0V
Current pulse
PA14, 15, 25
(N)PG60A(E),
PG30S
1, 2 EL0122 1: + (+24 or 12V DC) 2: −
2 EL0123 2: − Load 510Ω(*)
Pulse
Output
Open collector 4, 5
4:+
5:−
(Isolated only in Model EL0122)
Analog
Output
4-20mA DC 1, 2
1:+
2:−
Optional feature (Model EL0122 only)
If ① and ② are not used, do not fail to
short them out. Unless so shorted out,
no analog voltage output appears across
terminals 3 and 4.
1-5V DC 3, 4
3:+
4:−
Alarm
Output
Alarm 1 5, 6
Output signal: Non-contact relay ×2 points
Capacity: 230V AC/340V DC, 200mA
"ON" resistance: 16Ωmax. (Leak current 1μA min. at
"OFF")
Alarm 2 7, 8
◎Terminal Block Identification for External Connections
1. Power cannot be supplied to the transmitters of certain flowmeters, such as the
Thermistor Type Vortex Flowmeter, DC Power Type Coriolis Flowmeter, etc.
Prepare a power source separately, or relay it using another device.
2. An asterisk (*) indicates requirement for a separate power source.
To Next Page
