OWC Mercury Elite Pro Dual Assembly Manual & User Guide

MERCURY ELITE PRO DUAL
DEVICE SETUP
6
5. Install the upper hard drive (HDD1), as shown below. Insert the SATA power and
SATA data cables from the Mercury Elite Pro Dual into the SATA connectors on
the hard drive (NOTE: do not twist the black SATA data cable). Next, slide the hard
drive to line up the screw holes in the hard drive with those on the inner chassis.
Make sure the SATA connectors are seated rmly before continuing.
6. Using eight of the larger screws from the packet you removed earlier, fasten the
hard drives to the inner chassis. There are four screw holes on each side.

OWC Mercury Elite Pro Dual Specifications

General

Hot-swap	Yes
RAID levels	0, 1
Storage drive size	3.5 \
Total storage capacity	8000 GB
Number of storage drives supported	2
Interface	Thunderbolt
Product color	Aluminum
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	5 - 42 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Cache internal	128 MB

Weight and Dimensions

Depth	228.6 mm
Width	71.2 mm
Height	133.4 mm
