Oxy Heli 5 - Chapter 20: Main Blades & Tail Blades Installtion

Please look at Accessories for the shims you need
to adjust Main & Tail Blades thickness, in the kit
have included:
1
Set x OXY5 - Main Blade Plastic Spacer = 1.5mm thickness
1 Set x OXY5 - Main Blade Shim Silver = 0.5mm thickness
1 Set x OXY4 - Tail Blade Plastic Spacer = 1mm thickness
- For Main Blade have 10mm Root thickness please use
Main Blade Shim PLastic 1.5mm thickness
- For Main Blade have 12mm Root thickness please use
Main Blade Shim Silver 0.5mm thickness
Main Blade
M4x25 Hex Cap Screw
M4 Self Lock Nut 4 x Main Blade Shim
M3x16
Hex Cap Screw
Tail Blade
Tail Blade Shim
M3 Self Lock Nut
Chapter 20: Main Blades & Tail Blades Installtion
page 53
