Oxygen 8 SERENA - ERV Typical Installations; Horizontal and Vertical Installations

Installation Manual Serena Series
6.1 Horizontal and Vertical Installations
STRAPPING SYSTEM: (optional)
Allows one person installation for
vertical and horizontal installation.
UP
UP
PULL
DOWN
Strap
jtan
ta
y
0
1
.28.1
1
*
NOT SUPPLIED
1
.3
2
.
2
1
ya
t
n
a
t
j
1
Vibration
Spring
Washer
*
Screw*
CHAIN MOUNTING
SYSTEM:
(optional)
Available for both
horizontal & vertical
installation.
Chain
*
Backdraft
Damper
Concrete
Concrete
Wooden Joist
Bracket
(Supplied)
Grommet*
Washer*
Backdraft Damper
Screw
*
Flap
Flap
Backdraft Damper
28"
30"
14"
28"
14"
30"
30" clearance (300 cfm) and 34" clearance (500 cfm) is recommended for cleaning of the core and servicing the unit.
Dampers are installed for horizontal installation. For vertical installation, both dampers must be turned so they can open and close properly
when there is any backdraft.
Make sure no screw will interfere the function of the backdraft damper flaps while installing the duct work to the ERV.
Horizontal
Vertical
Note
After installation, make sure the/ERV is properly leveled. If not leveled correctly, then defrost will not perform eectively and/or
the unit may frost in winter.
6.0 ERV Typical Installations
