Ozito PSDW-780 - OPERATION; L-SHAPE CONNECTOR; FLOAT SWITCH

2. L-SHAPE CONNECTOR 3. FLOAT SWITCH
3. Screw the prepared
universal adaptor clockwise
onto the L-shape connector
NOTE. The hose/tube/
tap adaptor should not be
connected at this stage.
4. Securely attach the hose/
tube/tap adaptor to the
universal adaptor, t hose
clamps if you are using
exible hose or tube, and
tighten well.
2. Make sure the L-shape
connector is rmly
tightened so that the
O-ring is compressed
between the pump
housing and the
L-shape connector.
This ensures no leakage
will occur at this point.
OPERATION
Thepumpisttedwithaoatswitch,whichcontrolshow
the pump switches on and switches off.
Automatic mode
1. Screw the L-shape
connector into the pump
housing by rotating in a
clockwise direction
4. When the oat switch cable
is able to move freely the
pump will function down to
a water depth of 50mm and
automatically shut off
3. To set the pump to switch off
at a higher water level, insert
the oat switch cable into
the adjuster
100mm
minimum
NOTE: There must be a
minimum of 100mm of cable
from the adjuster to the oat.
1. When the oat switch is
about 30° higher than
horizontal (start up level) or
above the handle, the pump
will turn ‘on’ and operate
(water depth of 500mm)
30°
30°
2. When the oat switch is 30°
lower than the horizontal or
below the handle, the pump
will turn ‘off’. (water depth of
approximately 150mm)
1. When the oat switch is held in
the vertical position the pump will
run continuously.
CAUTION: To prevent the pump
running dry, this operating mode
is only allowed under supervision.
The pump must be switched off as
soon as no more water is emitted
from the discharge line.
Manual operation
When the pump is plugged into an outlet and left unattended it will
turn on when the oat switch turns on.
