Position Amount of Engine Brake
3 100%
4
*
100% AND engages MAX
mode.
The corresponding engine brake level (and
MAX mode) indicates on the engine brake
indicator.
Hill Start Aid (HSA)
Disable Switch
T
wo-position Switch
Positions:
• OFF (temporary position)
• (center
, resting position)
OFF Pressing the switch up temporarily disables the
Hill Start Aid feature. Disabling Hill Start Aid
presents both a Popup and a warning light (see
Hill Start Aid (HSA) Disabled Warning Light on
page 24
).
Hill Start Aid is automatically re-enabled
after the first successful launch.
Power Take-off (PT
O)
Switch (option)
Two-position Switch
Positions:
• ON
• OFF
ON Enables the PTO, starting the PTO activation
process.
OFF Disables the PTO.
This vehicle may be equipped with a dash-
mounted switch that controls PTO
engagement/disengagement. When the
operator activates the switch for the PT
O,
the status indicator light (located on the
switch) will immediately illuminate even
though PTO engagement may not have
occurred. If the PT
O is engaged and the
operator turns the switch OFF, the PTO
status indicator light (located on the switch)
will turn off immediately even though PTO
disengagement may not have occurred.
CAUTION
Increasing engine rpm before the PTO
is engaged
can prevent the PTO from
engaging and/or cause PTO damage.
Auxiliary Transmission
Switch (option)
Three-position Switch
Positions:
• LOW
*
This position is momentary and will revert back to position 3 when the shifter is released.
CONTROLS - Hill Start Aid (HSA) Disable Switch
Y53-1349-1A1 (02/2022) 31
