Pacific energy SUMMIT INSERT - Replacement Parts

20
SINC 250314-24
1......Bay Top (c/w Washers and Nuts) ................SINS.50374524-C
2......Casing Top, Back ............................................................. 3502
3......Casing Top, Front ........................................................ 3502.51
4......Casing Back...............................................................3504.001
5......Air De ector ..................................................................... 3505
6......Front Panel, Left .....................................................SINC.3563
7......Casing Side, Left ............................................... SINS.3509.51
8......Door Catch (c/w Bolt) .......................................WODC.1461A
9......Ash Lip ........................................................... SINS.50374523
10 ....Quadrant Shield ............................................................... 3561
11 ....Casing Bottom ..................................................................3501
12 ....Casing Side, Right ........................................................ 3503.5
13 ....Front Panel, Right ................................................... SINC.3564
14 ....Secondary Air Box Gasket ...................................... 5068.3237
15 ....Secondary Air Box (c/w Gasket) ..........................SUMM.3140
16 ....Quadrant Cover .......................................................................
356117 Air Shutter Assembly (c/w Spring. Washer and Cap) ..........
SINB.3537
18 ....Glass Clamp Kit (c/w Screws) ..............................SSER.1425
19 ....Glass Bar Kit (2 pcs.) .......................................SUMM.312501
........Glass Gasket Kit (not shown) .....................................2083.01
20....Rep. Glass (c/w Glass Gasket) .......................... DR46.GLKIT
21....Door Gasket Kit ............................................... DR46.WDGKIT
22....Door Casting, Arched Black ................................... CAST.46ST
........Door Casting, Arched Gold ................................. CAST.46GDA
.......... Door Casting Arched Nickel...............................CAST.46NI
.......... Door Casting Arched Brushed Nickel...............CAST.46BNA
23....Door Handle Assembly (c/w Wood Handle and Nut) ...............
WODC.4147C
24....Baffle Pin ........................................................... SSER.125001
25....Brick Rail Set(2 pcs. required) ......................SUMM.RAILSET
26....Baffle Kit (includes side insulation, 2pcs) .........SUMB.BAFKIT
27....Flame Shield (c/w Bolt, Washer and Nut) .............. SINB.3525
28....Boost Manifold .............................................................3105.01
29....Firebrick Set.......................................................BRIC.SUMMA
30....Replacement Blower Assembly ...............................................
........Right Blower Assy. .............................................SPND.502454
........Left Blower Assy. ................................................SPND.502453
31....Standard-Size Surround Assembly, Embossed Panels ...........
50" wide x 32" high
32....Control Box Mount, Right ..................................................3512
33....Control Box Mount, Left ................................................... 3529
34....Control Assembly ...................................................SPND.4583
........Cover Plate(not shown) ................................................... 4593
All parts may be ordered from your nearest Paci c
Energy dealer. Contact Paci c Energy for the location
of the dealer nearest you.
Replacement Parts
(WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION)
ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO.
