Page 22 For technical questions, please call 1-888-866-5797. ITEM 69746
SAFETY SETUP OPERATION MAINTENANCE
Parts Lists and Diagrams
Parts List
Part Description Qty.
1 Gasket, Cylinder Head 1
2 Cover Subassembly, Cylinder Head 1
3 Gasket, Cylinder Head Cover 1
4 Tube, Breather 1
5 Bolt 4
6 Stud 1
7 Stud 1
8 Stud 2
9 Pin 2
10 Bolt, Cylinder Head 4
11 Plug, Spark 1
12 Head Subassembly, Cylinder 1
13 Crankcase Subassembly. 1
14 Sensor, Engine Oil 1
15 Gear Assy, Governor 1
16 Arm, Governor 1
17 Bolt, Drain Plug 2
18 Washer 2
19 Bearing 1
20 Seal, Oil 1
21 Washer 1
22 Pin 1
23 Bolt 2
24 Cover, Crankcase 1
25 Bearing 1
26 Seal, Oil 1
27 Gasket, Crankcase 1
28 Pin 2
29 Dipstick Subassembly, Oil 1
30 Plug Subassembly, Engine Oil 1
31 Bolt 6
32 Crankshaft Assy. 1
33 Clip, Piston Pin 2
34 Piston 1
35 Pin, Piston 1
36 Rod, Connecting 1
37 Ring, The First 1
38 Ring, The Second 1
39 Ring Set, Oil 1
40 Camshaft Assy. 1
41 Valve, Exhaust 1
42 Valve, Intake 1
43 Seat, Valve Spring 1
44 Retainer, Exhaust Valve 1
45 Rotator, Valve 1
46 Guide, Seal 1
47 Tappet, Valve 2
48 Lifter, Valve 2
49 Plate Subassembly, Lifter Stopper 1
50 Bolt, Valve Adjusting 2
51 Rocker, Valve 2
52 Nut, Valve Adjusting 2
53 Nut, Valve Lock 2
54 Spring, Valve 2
55 Starter Assy, Recoil 1
56 Bolt 3
57 Shroud 1
58 Shroud, Cylinder Body 1
59 Shield,Lower 1
60 Protector, Oil 1
61 Switch Subassembly, Stop Engine 1
62 Bolt 2
63 Bolt 1
64 Collar 1
65 Bolt 1
66 Bolt 4
67 Carburetor Assy. 1
Part Description Qty.
68 Gasket, Air Cleaner 1
69 Gasket, Carburetor 1
70 Plate, Carburetor Insulator 1
71 Gasket, Carburetor Insulator 1
72 Nut 2
73 Cleaner, Air 1
74 Gasket, Exhaust Outlet 1
75 Nut 2
76 Muffler Assy 1
77 Tank, Fuel 1
78 Strainer, Fuel 1
79 Cover, Fuel Tank 1
80 Outlet Subassembly, Fuel Tank Oil 1
81 Clamp 3
82 Tube, Fuel 1
83 Bolt 1
84 Nut 2
85 Nut, Flywheel 1
86 Pulley,Starter 1
87 Impeller 1
88 Flywheel Subassembly 1
89 Bolt 2
90 Coil, Ignition 1
91 Control Assy, Throttle 1
92 Bolt 2
93 Spring, Governor 1
94 Rod, Governor 1
95 Spring, Throttle Valve Returning 1
96 Bolt, Governor Support 1
97 Nut 1
98 Support Subassembly, Governor 1
99 Hoop Subassembly, Hose 3
100 Joint, Water Tube 1
101 Strainer 1
102 Bolt 6
103 Washer 6
104 Plug, Thread 2
105 Washer, Screw Plug 2
106 Pump Body 1
107 Gasket, Inlet Water 1
108 Case, Whorl 1
109 Whorl Case Seal 1
110 Bolt 5
111 Gasket 1
112 Impeller, Water Pump 1
113 Key 1
114 Washer 1
115 Seal, Porcelain 1
116 Seal Assy, Mechanism 1
117 Cushion, Water Pump Joint 1
118 Washer 4
119 Pin 1
120 Pin 1
121 Joint, Water Pump 1
122 Pump Assy, Water 1
123 Frame Assy, Engine 1
124 Bolt 4
125 Seat, Engine Frame Shock Absorption 4
126 Nut, Acorn 4
127 Bolt 4
128 Nut 6
129 Washer 2
130 Bolt 2
131 Jacket, Rubber 1
132 Valve, One Way 1
133 Clamp 1
134 Hose, Fuel Steam Rubber 1
To Next Page
