94
SECTION 7
SERVICE
7.0 SERVICE
This section describes service of the AMX-Series AC Power Source.
7.1 SERVICE PROCEDURE
The AMX-Series Power Source contains no user serviceable parts. Service is accomplished
by returning the unit to the factory or authorized service center. Under some circumstances,
the factory may authorize the user to perform limited sub-assembly or component changes as
deemed allowable by the factory service representative. For this purpose, many
sub-assembly and component level Pacific Power Source part numbers have been included
here. Part numbers for various components are listed separately for each Model.
When questions regarding operation arise or service is required, call the factory for
instructions. Pacific Power Source maintains a staff of highly trained technicians who are
ready to assist. Website: www.pacificpower.com; Email: support@pacificpower.com or
sales@pacificpower.com.
7.2 ROSTER OF SYSTEM LEVEL FACTORY PART NUMBERS
The following is a list of system level factory part numbers for the models which comprise the
AMX-Series line of equipment. Part numbers are stated for reference.
ASSEMBLY NAME ASSEMBLY NUMBER
MODEL 105-AMX 500 VA AC Power Source 143141
MODEL 108-AMX 750 VA AC Power Source 143142
MODEL 112-AMX 1.2 kVA AC Power Source 143146
MODEL 125-AMX 2.5 kVA AC Power Source 143125
MODEL 140-AMX 4.5 kVA AC Power Source 143140
MODEL 160-AMX 6.0 kVA AC Power Source 143161
MODEL 305-AMX 500 VA AC Power Source 143143
MODEL 308-AMX 750 VA AC Power Source 143144
MODEL 312-AMX 1.2 kVA AC Power Source 143147
MODEL 320-AMX 2.25 kVA AC Power Source 143160
MODEL 345-AMX 4.5 kVA AC Power Source 143126
MODEL 360-AMX 6.0 kVA AC Power Source 143127
MODEL 390-AMX 9.0 kVA AC Power Source 143128
MODEL 3120-AMX 12.0 kVA AC Power Source 143129
Transformer assembly for the 105, 108-AMX P000919
Transformer assembly for the 305, 308-AMX 139410
Magnetics Module for the 140, 160, 320, 345, 360, 390, 3120-AMX 134350
UPC12 Programmable 1
Controller 133700
UPC32 Programmable 3
Controller 133600
UPC1 Programmable 1
Controller 141102
UPC3 Programmable 3
Controller 141302
UMC31 Programmable 3
Controller 133500
