SECTION 7 SERVICE
96
7.3.3 FACTORY PART NUMBERS, MODEL 112-AMX (PART NUMBER 143146)
SUB-ASSEMBLY FACTORY PART No.
Power Amplifier PCB: 139070
LED Display PCB: 139071
Output Filter PCB: 139073
Low Voltage Power Supply/Fan Speed Cont. PCB: 139074
Power Factor Correction PCB: 139075
Control/Logic PCB: 139078
Input Filter PCB: 140079
LVPS Fuse PCB: 140373
CHASSIS COMPONENT FACTORY PART No.
Input Circuit Breaker: 716070 or 716075 for CE
Front Panel Handle: 702112
Output Terminal Block: 705077
Output Terminal Block Cover: 705082
External Sense Terminal Block: 705076
External Sense Terminal Block Cover: 705081
Input Power Cord Strain Relief: 779009
Input Transformer (T1): 531318
Low Voltage Input Transformer (T2): 531290
Output Relay: 717040
Power Amplifier Fan: 703145
Input Transformer Fan: 703198
7.3.4 FACTORY PART NUMBERS, MODEL 125-AMX (PART NUMBER 143125)
SUB-ASSEMBLY FACTORY PART No.
Control/Metering PCB: 134170
Voltage Amplifier PCB: 134671
LED Display PCB: 139071
Power Amplifier PCB: 139670
Input Filter PCB: 140078
Output Filter PCB: 143372
LVPS Fuse PCB: 140374
CHASSIS COMPONENT FACTORY PART No.
Input Circuit Breaker: 716059 or 716074 for CE
Front Panel Handle: 702112
Trunk Handle: 702128
Input and Output Terminal Block: 705080
Input Terminal Block Cover 143315
Input Transformer: 531304
Input Power Supply Bridge Rectifier: 743011
Input Power Supply High Voltage DC Capacitor: 720588-41
Output Relay: 717043
Power Amplifier Fan: 703145
