Pacific Power Source 345-AMX - Figure 4.1 Front Panel Controls

SECTION 4 OPERATION
82
4.1 FRONT PANEL CONTROLS (cont.)
MODEL 320−AMX
w/ UPC−32 Controller
INPUT POWER SWITCH
OUTPUT COUPLING INDICATORS
OUTPUT FORM INIDCATORS
OUTPUT POWER SWITCH
and INDICATORS
2.
1.
3.
4.
FIGURE 4.1 FRONT PANEL CONTROLS
