Vertically Mounted Type KPV
11X
12B
8J
19B
21F
1A
5D
17S
19A
20J
23B
26K
4A
12A
17E
13G
16D
18B
16F
16L
26K
11X
5A
98M
12B
1A
3D
1L
14M
18A
19A
20J
23C
23A
61P
17E
13G
16D
6A
16F
16L
26K
14A
ITEM
NO.
1A
1L
3D
4A
4B
5A
5D
5L
6A
7A
10K
PART
NAME
Upper Case
Lower Case
Impeller
Wear Ring
Casing Wear Ring
Shaft Sleeve
Shaft Sleeve
Lantern Ring
Pump shaft
Packing Gland
Packing Retainer
ITEM
NO.
11X
12A
12B
13A
13G
14A
16D
16L
17E
17S
18A
PART
NAME
Gasket
Key
Coupling Key
Packing Ring
Water Slinger
Seal Seat
Plug
Plug
O-Ring Gasket
O-Ring Gasket
Bearings
ITEM
NO.
18B
19A
19B
20J
23B
26J
26K
61J
61P
98M
23A
23C
PART
NAME
Bearings
Bearing Caps
Bearing Caps
Base
Coupling Half
Bearing Housing
Bearing Housing
Retaining Rings
Retaining Rings
Roll Pin
Coupling Half
Grid
