PageFlip Dragonfly User Guide 5. PRODUCT SPECIFICATION
5 PRODUCT SPECIFICATION
Item Specifications
Model Name PageFlip Dragonfly
Model Number PFDRAGONFLY-01
Dimensions 6.8 x 5.8 x 1.4 inches (173 x 147 x 36 mm)
Weight (w/o batteries) 9.6 ounces (271.2 grams)
Power Requirements 3V, 40mA (2 AA batteries)
Power Consumption:
Operating Mode 4.4-6.8 mA
Bluetooth Pairing 1.4-50 mA
Standby 0.24-4.1 mA
Sleep 0.302 mA
Pedal light 5 mA additional
Battery Life (2 AA batteries):
Pedal light off 400 hours of continuous tur ning (200K page turns)
Pedal light on 200 hours of continuous tur ning (100K page turns)
Output Power -1.86dBm
Operating Distance 10 meters
Operating Frequency 2402-2480 MHz
Operating Temperature 32
◦
− 140
◦
F (0
◦
C - 60
◦
C)
Storage Temperature −40
◦
− 176
◦
F (−40
◦
- 80
◦
C)
Warranty One year
LED Operating Condition
Off Pedal powered off or asleep
Solid Connected to external power source
All LEDs flash Bluetooth discovery mode (BLUETOOTH RESET)
Quick flash (1 sec) Attempting to pair with computer
Slow flash (4 sec) Paired with computer
Three quick flashes Low-battery condition
PageFlip, Inc. 23 www.pageflip.com
