Pagsta BOBBER - Clutch Adjustment

27
Free play at the tip of the left clutch lever is 10 to 20mm. If adjustment is necessary, unscrew
the lock nut positioning the clutch cable on the locator of the crankcase and adjust it. Turn
the lever as (A) shows to decrease free play. Turn as (B) shows to increase.
The same for the adaptor on the left clutch lever.
CLUTCH ADJUSTMENT
A
B
1¢ÙLocator
¢2ÚLock nut
3ÛAdjuster
3
Adjuster
