38
Remove the right guard board by loosening the hexangular bolt on the main seat and open the
fuse box (white) to check fuses. There are 2 spare fuses for your motorcycle included.
Reinstall the guard board in reverse order after replacement.
The specified fuses are 15A.
When frequent fuse failure occurs, it usually indicates a short circuit or an overload in the
electrical system. See your authorized PAGSTA dealer or service center for repair.
Caution: Replace with the specified fuse. Never use other conductive materials for replacement.
Turn the ignition switch off before checking or replacing fuses to prevent accidental short-
circuiting. To replace the fuse in the fuse box, remove the fuse box cover. Pull the old fuse out of
clips. Push a new fuse into the clips and install the fuse box cover.
Fuse location
FUSE REPLACEMENT
