Setting up the machine
36
ubject to change without notice
Adjust pressure axle/ contact rollers:
1. Adjust the pressure axle (9) using the knurled screw (10)
Ö Adjust equally on both sides
Ö Loosen the set screw on the contact rollers (11)
Ö Adjust the contact rollers to the product
Ö Tighten set screw
Pressure axle / contact rollers
Abb.1654
Knurled screw contour pre-setting
3.2.a
10
11
9
